Everything You Need to Know Before Installing an EV Charger
Seth Mckay
7/27/20263 min read
As electric vehicles become more popular across British Columbia, more homeowners are looking to install a home EV charger. Charging at home is convenient, reliable, and often more cost-effective than relying on public charging stations.
Before installing an EV charger, it's important to understand your options, your home's electrical capacity, and whether you actually need an electrical service upgrade. In many cases, there are more affordable solutions available.
At Starpoint Electric, we help homeowners find the safest and most cost-effective way to charge their electric vehicles.
Level 1 vs. Level 2 Charging
The first decision is choosing between a Level 1 and Level 2 charger.
Level 1 Charging
A Level 1 charger plugs into a standard 120-volt household outlet. Most electric vehicles include one from the manufacturer.
Pros
No installation required
Lowest upfront cost
Suitable for low daily driving distances
Cons
Slow charging speeds
May take 24 hours or more for a full charge
Not ideal for drivers with longer daily commutes
If you only drive short distances each day and can leave your vehicle plugged in overnight, a Level 1 charger may be enough.
Level 2 Charging
A Level 2 charger operates on a 240-volt circuit, similar to an electric range or clothes dryer.
Pros
Significantly faster charging
Convenient overnight charging
Better suited for most homeowners
Can support future EV purchases
Cons
Requires professional installation
Higher upfront cost
For most households, a Level 2 charger offers the best balance of convenience and performance.
How Fast Will My EV Charge?
Charging speed depends on several factors, including your vehicle, the charger, and the electrical circuit available.
In general:
Level 1 (120V): Approximately 5–8 km of range per hour.
Level 2 (240V): Approximately 30–70 km of range per hour, depending on the charger and vehicle.
Many drivers can fully recharge their vehicle overnight using a properly installed Level 2 charger.
Electrical Requirements
Every home is different.
Before installing an EV charger, we evaluate:
Your existing electrical panel.
Available breaker space.
Your home's electrical service size.
Current electrical demand.
Future electrical plans, such as adding a heat pump or hot tub.
The Canadian Electrical Code requires that your home's electrical system be capable of safely supplying the additional load. A professional load calculation helps determine the best installation approach.
Do You Need a Service Upgrade?
One of the biggest misconceptions is that every EV charger requires upgrading to a 200-amp electrical service.
The reality is that many homeowners do not need a service upgrade.
A proper electrical assessment often identifies other safe, code-compliant solutions that can save thousands of dollars.
Rather than automatically recommending a larger service, we evaluate your home's actual electrical demand and future plans before making a recommendation.
Smart EV Chargers
Many modern chargers include smart features that make charging more convenient and efficient.
Depending on the model, these features may include:
Smartphone app control
Scheduled charging during off-peak electricity hours
Energy usage tracking
Remote monitoring
Software updates
Integration with home energy management systems
These features can help reduce operating costs while giving you greater control over your charging schedule.
Load Management Systems: A Smarter Alternative
One of the most overlooked options when installing an EV charger is a load management system.
Instead of increasing the size of your electrical service, a load management system continuously monitors your home's power usage.
When household electrical demand is low, your EV charges at full speed.
If your home begins using more electricity—for example, if the oven, dryer, heat pump, and hot water tank are all operating simultaneously—the system automatically reduces or temporarily pauses EV charging to ensure your home's electrical service is never overloaded.
Once additional electrical capacity becomes available, charging automatically resumes.
For many homeowners, this provides the convenience of a Level 2 charger without the expense of a service upgrade.
Depending on the property, this solution can save thousands of dollars while remaining fully code compliant.
Are There EV Charger Rebates?
Rebate programs can change over time and may be offered by BC Hydro, CleanBC, municipalities, or other organizations.
Eligibility often depends on:
The type of charger installed.
The property type.
Program availability at the time of installation.
Because rebate programs are updated regularly, we recommend checking current incentives before beginning your project. We're also happy to point you toward available programs and help ensure your installation meets any applicable requirements.
Why Hire a Licensed Electrician?
Installing an EV charger involves much more than mounting equipment on a wall.
A proper installation includes:
Performing a load calculation.
Determining the correct circuit size.
Selecting appropriate wire and breaker sizes.
Ensuring the installation complies with the Canadian Electrical Code.
Obtaining permits where required.
Testing the installation for safe operation.
Choosing a licensed electrical contractor helps ensure your charger operates safely and reliably for years to come.
Let Starpoint Electric Help
Whether you're purchasing your first electric vehicle or adding another charger to your home, Starpoint Electric can help you determine the best solution for your property.
We'll assess your existing electrical system, explain your options, and recommend the most practical approach—whether that's installing a new circuit, upgrading your electrical service, or using a load management system to avoid unnecessary costs.
If you're considering a home EV charger in Maple Ridge, Pitt Meadows, Langley, Mission, Coquitlam, Port Coquitlam, Surrey, or the surrounding areas, contact Starpoint Electric today to schedule a consultation.
